Square Hollow Sections made of Stainless Steel A554 Gr 304L are commonly used structural elements that provide strength, durability, and aesthetic appeal. We shall examine the characteristics, uses, and advantages of A554 Gr 304L square hollow sections in this post. Stainless steel grade A554 Gr 304L is renowned for its superior corrosion resistance, high strength, and exceptional formability. It is a common 304 stainless steel that has been modified to be low-carbon, making it appropriate for a variety of uses where corrosion resistance is essential. The grade's name contains the letters "L" for "low carbon," signifying a lower carbon concentration that, in some conditions, helps prevent sensitization and the associated corrosion.

Metal hollow profiles with square-shaped cross sections are known as square hollow sections. They have accurate dimensions and smooth surfaces since they are produced using cold-forming techniques. Square hollow sections made of A554 Gr 304L are offered in a variety of diameters, thicknesses, and lengths for simple integration into a variety of structural, industrial, and architectural applications. The ability of stainless steel square hollow parts to resist corrosion is one of their main benefits. Applications in hostile environments, such as marine, chemical, and industrial settings, where resistance to corrosion and staining is essential, are particularly well suited for A554 Gr 304L. Even under difficult circumstances, it will perform for a very long time because to its sturdy construction. Stainless steel's prominence in architectural applications is boosted by its visual appeal.

Additionally providing strength and structural integrity, these hollow parts. In engineering, infrastructure, and building projects, they are widely used. Square hollow sections made of A554 Gr 304L are appropriate for uses like building frames, supports, columns and beams because they can sustain enormous loads and offer stability. Square hollow parts made of stainless steel are strong and resistant to corrosion, among other advantages. They are environmentally beneficial because they are recyclable, non-magnetic, and fire-resistant. Long-term cost-effectiveness is a result of their robustness and low maintenance needs. In conclusion, Stainless Steel A554 Gr 304L Square Hollow Sections are strong, dependable structural elements that are utilised in a variety of applications and industries.

Stainless Steel A554 Gr 304L Square Hollow Sections Specification

Buy DIN 1.4306 SS Square Hollow Section Pipes, Stainless Steel UNS S30403 SHS Pipe, A554 SS 304L Structural Square Hollow Sections

Stainless Steel A554 Gr 304L Square Hollow Section Sizes:

Size mm	kg/m	Size mm	kg/m
20 x 20 x 2.0	1.12	20 x 20 x 2.5	1.35
25 x 25 x 1.5	1.06	25 x 25 x 2.0	1.43
25 X 25 X 2.5	1.74	25 X 25 X 3.0	2.04
30 X 30 X 2.0	1.68	30 X 30 X 2.5	2.14
30 X 30 X 3.0	2.51	40 x 40 x 1.5	1.81
40 x 40 x 2.0	2.31	40 x 40 x 2.5	2.92
40 x 40 x 3.0	3.45	40 x 40 x 4.0	4.46
40 x 40 x 5.0	5.40	50 x 50 x 1.5	2.28
50 x 50 x 2.0	2.93	50 x 50 x 2.5	3.71
50 x 50 x 3.0	4.39	50 x 50 x 4.0	5.72
50 x 50 x 5.0	6.97	60 x 60 x 3.0	5.34
60 x 60 x 4.0	6.97	60 x 60 x 5.0	8.54
60 x 60 x 6.0	9.45	70 x 70 x 3.0	6.28
70 x 70 x 3.6	7.46	70 x 70 x 5.0	10.11
70 x 70 x 6.3	12.50	70 x 70 x 8	15.30
75 x 75 x 3.0	7.07	80 x 80 x 3.0	7.22
80 x 80 x 3.6	8.59	80 x 80 x 5.0	11.70
80 x 80 x 6.0	13.90	90 x 90 x 3.0	8.01
90 x 90 x 3.6	9.72	90 x 90 x 5.0	13.30
90 x 90 x 6.0	15.76	90 x 90 x 8.0	20.40
100 x 100 x 3.0	8.96	100 x 100 x 4.0	12.00
100 x 100 x 5.0	14.80	100 x 100 x 5.0	14.80
100 x 100 x 6.0	16.19	100 x 100 x 8.0	22.90
100 x 100 x 10	27.90	120 x 120 x 5	18.00
120 x 120 x 6.0	21.30	120 X 120 X 6.3	22.30
120 x 120 x 8.0	27.90	120 x 120 x 10	34.20
120 X 120 X 12	35.8	120 X 120 X 12.5	41.60
140 X 140 X 5.0	21.10	140 X 140 X 6.3	26.30
140 X 140 X 8	32.90	140 X 140 X 10	40.40
140 X 140 X 12.5	49.50	150 X 150 X 5.0	22.70
150 X 150 X 6.3	28.30	150 X 150 X 8.0	35.40
150 X 150 X 10	43.60	150 X 150 X 12.5	53.40
150 X 150 X 16	66.40	150 X 150 X 16	66.40
180 X 180 X 5	27.40	180 X 180 X 6.3	34.20
180 X 180 X 8	43.00	180 X 180 X 10	53.00
180 X 180 X 12.5	65.20	180 X 180 X 16	81.40
200 X 200 X 5	30.50	200 X 200 X 6	35.8
200 x 200 x 6.3	38.2	200 x 200 x 8	48.00
200 x 200 x 10	59.30	200 x 200 x 12.5	73.00
200 x 200 x 16	91.50	250 x 250 x 6.3	48.10
250 x 250 x 8	60.50	250 x 250 x 10	75.00
250 x 250 x 12.5	92.60	250 x 250 x 16	117.00
300 x 300 x 6.3	57.90	300 x 300 x 8	73.10
300 x 300 x 10	57.90	300 x 300 x 8	90.70
300 x 300 x 12.5	112.00	300 x 300 x 16	142.00
350 x 350 x 8	85.70	350 x 350 x 10	106.00
350 x 350 x 12.5	132.00	350 x 350 x 16	167.00
400 x 400 x 10	122.00	400 x 400 x 12	141.00
400 x 400 x 12.5mm	152.00	400 x 400 x 16	192

Stainless Steel A554 Gr 304L Square Hollow Section Grades

Ready Stock of Stainless Steel A554 Gr 304L Square Hollow Section

ASME SA554 304L Stainless Steel Square Hollow Section Equivalent Grades

Stainless Steel A554 Gr 304L Square Hollow Section Chemical Composition

Stainless Steel A554 Gr 304L Square Hollow Section Mechanical Composition

Stainless Steel A554 Gr 304L Square Hollow Sections Updated Price List

Request the latest AISI 304L Stainless Steel Square Hollow Section Tube List. Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Ranfit Metals & Alloys maintains a stock of all standard items and can export them at best price for Grade 304L A554 SS Square Tube.

Ranfit Metals & Alloys is a ISO approved certified AISI 304L Stainless Steel Square Hollow Section Tube exporter in India. We are known as a trusted vendor as a A554 SS 304L Structural Square Hollow Sections, Gr 304L SS ASTM A554 SHS Tubing distributor & dealer in your country. Our 304L Stainless Steel Welded Square Tubes are tested to international standards, and specifications as per DIN, JIS, EN, ASTM etc. We have huge stock in Asia, GCC, Gulf, Middle east, UK to supply with over 28 countries, we provide after sales service and fast delivery.
